1P POLE MOUNTED DISTRIBUTION TRANSFORMER-AUX Smart technology

Product Features

Easy to install, aesthetically pleasing appearance

No leakage during the whole life cycle

Low noise, small size, light weight

Wound core structure, low no-load loss, remarkable economic benefits

Technical Parameter

Dimensions
CLASS: 15kV
MODEL:D1-50-13200-120/240		FAMILY: TP-1-15
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	10	15	25	37.5	50
A	1150	1150	1150	1190	1190
B	800	800	800	840	840
ΦC	561	561	561	561	561
ΦD	690	690	690	690	690
E	643	643	643	683	683
F	813	813	813	853	853
WEIGHT(kg)	210	215	225	240	250

CLASS: 25kV
MODEL:D1-100-23000-120/240		FAMILY: TP-1-25
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	10	15	25	37.5	50
A	1185	1185	1185	1185	1185
B	800	800	800	800	800
ΦC	561	561	561	561	561
ΦD	690	690	690	690	690
E	703	703	703	703	703
F	823	823	823	823	823
WEIGHT(kg)	487	497	512	537	549

CLASS: 34.5kV
MODEL:D3-75-33000-120/240		FAMILY: 34.5
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	10	15	25	37.5	50
A	1250	1250	1250	1335	1335
B	720	720	720	800	800
ΦC	475	475	475	561	561
ΦD	605	605	605	690	690
E	650	650	650	718	718
F	780	780	780	833	833
WEIGHT(kg)	492	502	539	549	574

Note:

1,The manufacturing program includes self-protectedtransformers for normal and hot environments.

2,This product is a custom class, special requirements canbe customised according to customer requirements.

CAPABILITIES, TEST AND ACCESSORIES
CAPABILITIES
SINGLE PHASE
kVA	Class 15	Class 25	Class 34.5
15	D	D	D
25	D	D	D
37.5	D	D	D
50	D	D	D
75	D	D	D
100	D	D	D
150	D	D	D
D=Avilable

TEST		COMPONENTS
Routine Test	Type test (Optional)	Accessories(Optional)
Ohmic resistance of the windings	Short circuit test	Hanging bracket
Insulation resistance(1 min)	Temperature rise test	Handles to attach to the pole
Dielectric strength of the insulating liquid	Lighting impulse test	Drain and sampling plug
Applied voltage	Power factor of the insulating liquid	Insulating liquid level mark
Induced voltage test	Power factor of the insulation as a whole	Outdoor operation lead changer
Transformation relation	Air tightness	Lifting accessories
Polarity and phase sequence		Tank ground connection
No load losses		Low voltage ground jumper
Excitation current		Overpressure relief valve
Load losses		Medium voltage terminal bushings
Impedance voltage		Low voltage terminal bushings
Air tightness		Oil filling valve
Coating thickness		Oil thermometer
Note: The distribution transformers have been tested in compliance with international IEC standards in accredited laboratories according to the ISO/IEC 17025 standard.		Note: Some accessories are according to customer's requirements.
