3P POLE MOUNTED DISTRIBUTION TRANSFORMER-AUX Smart technology

Product Features

Low noise

Compact structure,small footprint

High-quality insulation oil(vagetable oil、mineral oil), and the Vegetable oil is environmentally friendly and has a high ignition point

Hermetically sealed structure design, maintenance free, no leakage during the whole life cycle

Technical Parameter

Dimensions
CLASS: 15kV
MODEL:D3-50-13200-220Y/127		FAMILY: TP-3-15
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	15	30	45	75	150
A	1140	1140	1140	1140	1140
B	980	980	1040	1140	1160
C	825	825	875	875	875
D	750	750	800	880	880
E	580	580	600	640	640
F	780	780	800	840	840
WEIGHT(kg)	475	495	505	535	590

CLASS: 25kV
MODEL:D3-150-23200-220Y/127		FAMILY: TP-3-25
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	15	30	45	75	150
A	1265	1265	1265	1265	1265
B	1360	1360	1360	1360	1360
C	975	975	975	975	975
D	920	950	950	1050	1050
E	700	700	700	700	700
F	910	910	910	910	910
WEIGHT(kg)	625	640	655	675	715

CLASS: 34.5kV
MODEL:D3-150-33200-220Y/127		FAMILY: TP-3-34.5
DIMENSIONS(mm)	CAPABILITIES(kVA)
DIMENSIONS(mm)	15	30	45	75	150
A	1280	1300	1300	1350	1395
B	1180	1180	1180	1280	1400
C	910	910	910	910	1010
D	1010	1010	1010	1070	1120
E	700	700	700	700	700
F	825	845	845	880	920
WEIGHT(kg)	805	830	850	880	975

Note:
1. The transformer may or may not have radiators, according to customer requirements.
2. This product is a custom class, special requirements can be customised according to customer requirements.

CAPABILITIES, TEST AND ACCESSORIES
CAPABILITIES
SINGLE PHASE
kVA	Class 15	Class 25	Class 34.5
15	D	D	D
30	D	D	D
45	D	D	D
75	D	D	D
112.5	D	D	D
150	D	D	D
D=Avilable

TEST		COMPONENTS
Routine Test	Type test (Optional)	Accessories(Optional)
Ohmic resistance of the windings	Short circuit test	Hanging bracket
Insulation resistance(1 min)	Temperature rise test	Handles to attach to the pole
Dielectric strength of the insulating liquid	Lighting impulse test	Drain and sampling plug
Applied voltage	Power factor of the insulating liquid	Insulating liquid level mark
Induced voltage test	Power factor of the insulation as a whole	Outdoor operation lead changer
Transformation relation	Air tightness	Lifting accessories
Polarity and phase sequence		Tank ground connection
No load losses		Low voltage ground jumper
Excitation current		Overpressure relief valve
Load losses		Medium voltage terminal bushings
Impedance voltage		Low voltage terminal bushings
Air tightness		Oil filling valve
Coating thickness		Oil thermometer
Note: The distribution transformers have been tested in compliance with international IEC standards in accredited laboratories according to the ISO/IEC 17025 standard.		Note: Some accessories are according to customer's requirements.
